Description
Duplex Zipcord Armored Indoor Cable
| Application： | |||
| ☆.Adopted to indoor distribution.. | |||
| ☆.As pigtail of communication equipment. | |||
| ☆.Suitable for communication equipment served. | |||
| ☆.Can be installed conveniently and perated simply. |
| Characteristics： | |||||
| ☆.0.6 tight buffer fiber, | |||||
| ☆.High strength kevlar yarn member. | |||||
| ☆.Steel armored flexble tube.increase the cable’s twist | |||||
| resistance. |
| Technical Parameters: | ||||||||||
| Out Diameter | Inner Diameter |
Weight | Minimum allowable Tensile Strength (N) |
minimum allowable Crush Load （N/100mm) |
Minimum Bending Radius (MM) |
Storage temperature |
||||
| （MM) | （MM) | （KG) | short term | long term | short term | long term | short term | long term | （℃） | |
| 2.8×5.8 | 0.9 | 35.00 | 1000 | 300 | 1000 | 500 | 20D | 10D | -20+60 | |
| 3.0×6.2 | 0.9 | 35.00 | 1000 | 300 | 1000 | 500 | 20D | 10D | -20+60 | |
| Optical Characteristics | ||||||||||
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber | ||||||
| A1b:62.5/125 | ||||||||||
| Singlemode | G.652(A、B、C、D） | B1.1:Conventional fiber | ||||||||
| G.653 | B2: Zero dispersion shifted | |||||||||
| G.654 | B1.2 :Cut-off wavelength shifted | |||||||||
| G.655 | B4: Main technical data for positive dispersion shifted single-mode fiber |
|||||||||
–
–
